4 Axis CNC Wood Router with Rotary Device in South Africa, Chile, Canada
☆ The entry-level 4×8 rotary axis wood CNC router is widely used by small woodworking shops to make crafts, advertising signs, boards, nameplates, letters, and various furniture. Besides, the rotary device can realize 3D processing on rods, square sticks, rubber rods, etc.
4 Axis CNC Router Machines Video
Features
- It is provided with a rotary device for making furniture legs, columns, stair railings, statues, etc.
- The vacuum worktable has a strong adsorption capacity to prevent the panel from sliding or moving during operation.
- Its Z-axis travel is 400mm, which is suitable for processing thick and tall workpieces.
Parameters
| Serial Number | S20191125Y |
| Model | ELECNC1325-4 |
| Working area | 1300*2500*400mm |
| Spindle | 3.5kw HQD air cooling spindle |
| Inverter | Taiwan Fuling inverter |
| Control system | Mach 3 4 axis control system |
| Motor and driver | 750W Leahshine easy servo motor and driver |
| Working Table | T-slot & vacuum working table |
| limit switch | Japan OMRON limit switch |
| Lubrication system | Manual lubrication |
| Voltage | 220V, 1PH，60HZ |
Application
4 Axis CNC router has an swing spindle. It can change the direction automatically during the machining process without stopping. The 4 Axis CNC router has a wide range of applications in furniture, advertising, mold, decoration, construction and other fields and industries. In terms of functions, it can cut, engrave, drill, mill and groove. In regard to materials, 4 Axisrouter can process various wood materials, plastics, stone, soft metals and composites.
